Remark: Different functions of Side Key 1, Side Key 2, which are used by the long press or a short press, can be defined by programming
software.
The following functions can be defined:
Side Key:
1.None
2.Monitor(Analog)
3 Permanent Monitor(Analog)
4. Zone Selection
5. High / Middle / Low power selection
6.Repeater / Talk Around
7. Electricity Inquiry
8. Bluetooth Switch On / Off
9. Scan On / off

Basic Operations

POWER ON and POWER OFF:
Rotate the knob clockwise until a "click" is heard, transceiver will have a short beep sound,
indicating power on detecting success.
Attention:
If your transceiver is not power on, please check the battery,and confirm if the battery has been
charged and installedcorrectly. If it still can not be turned on, please contact with the agent.
To turn off the transceiver, please rotate the power knob / Volume knob anticlockwise until a
"click" is heard, then transceiver is power off.
Adjust Volume
When the transceiver is power on, rotate the power switch / Volume knob to adjust the volume.
Clockwise rotation to increase the volume;
Anticlockwise rotation to decrease the volume.
You can press the side key which is programmed MONITOR function to monitor the current volume
Attention: MONITOR key can be set to P1 or P2 Key according to the programming software.
Channel Selection:
Rotation the channel knob to select the desired channel. This transceiver has 128 channels.
Attention:
There are 8 zones in this transceiver, each zone has 16 channels, Zone can be selected by
pre-programmed key.
Transmit
When going to transmit, press PTT key, keep microphone away from your mouth about
3-4cm,and speak in your usual tone.
Receive
Release the PTT key to receive. Adjust the suitable volume to get the best receiving result.

Function Specification

LED indicator
LED indicator shows transceiver's working status.
Red light indicates the transceiver is transmiting.
Green light indicates the transceiver is on process of power on or is receiving non-encrypted signal or data.
Blue light indicates the transceiver Bluetooth is power on.
Call (PTT) key
Each channel in this transceiver can be set into a digital channel.
When in transmitting, press PTT key continuous will transmit signals to other transceivers continuously.
Press PTT to transmit and release PTT to receive. The microphone will be activated by pressing PTT
Receive and Transmit Call
Zone Selection
The zone is a group of channels.The transceiver supports at most 8 zones, and each zone is not more than 16 channels.
1.Press the pre-programmed Zone key.
2.You will hear a "confirmed" tone, and each time you press the intercom, it will cycle through a zone from low to high.
3.Rotate the channel knob to choose the desired transmitting channel.
Receive and Reply Call
You can received or reply call after finished channel / user ID or group ID's setting. When transmitting transceiver, LED indicator turns red.
When receiving message, the LED indicator turns green.
Receive and Reply Group Call
To receive a call from a user's group, the transceiver must be configured as belonging to that group.
1.LED indicator turns green.
2.Hold the transceiver vertically and keep about
1~2inches(2.5-5.0cm) away from mouth.
3.Press PTT key to respond the call, LED indicator turns red.
4.Release PTT key to receive.
