13.Instructions for use of laser light and white light
In the power-on state, click the "Laser light button" button to turn on/off the laser light. The machine emits a red
laser beam to position the shooting direction.
In the power-on state, click the "white light button" button to turn on/off the white light, the machine emits white
light, which acts as an illuminator.
14.Connect to the computer
The product software is divided into the following two versions:
① Equipment for installing U disk version software: directly connect to the computer without installing any
drivers, and directly connect to the computer with the data cable delivered with the machine;
② Equipment for installing police software: drivers need to be installed. For driver installation methods and
software usage, please refer to the software instructions in the CD.
15.Intercom (shoulder microphone function)
1. Connect the law enforcement instrument and walkie-talkie
through a dedicated intercom cable.
2. Press and hold the "Video/Intercom button" to talk, release
the button to stop the talk, the content of the talk will not be
stored on the memory card.
Connection diagram of the walkie-talkie and law
enforcement instrument

3.Product Parameter

Video Input
Display
Camera Angel
Range of Focus
Photosensitive device
Size
Video Camera
Video
Picture Resolution
Image Format
Exposure modeInfrared
Nigh Version Function
Infrared Night Version
Reservation record
Other Function
Audio
Pick-up
Memory
Shutter/shutter speed
Filter Switcher
White balance
USB Port
Built-in Li-on Battery
Working Temperature
Working voltage
Password protection
Parameter
2304*1296
2 inch 16:9 TFT LCD 960*240
Built-In Camera 170°angle lens
0.3~Infinity
1/3" Color CMOS
78*54.8*31.1mm (Length×wide×High)
JPG Max Pixel: 36 mega pixels
H.264 2304×1296，30 Frame/s；1920×1080，30Frame/s；
1280×720，60 Frame/s；1280×720,30 Frame/s
MP4
32M，30M，23M，20M，18.5M，16M,4M
JPEG
Automatic Exposure
Built-in 8 powers infrared light, support night photo and video, can distinguish
faceswithin 15 meters
15s
Flashlight, Laser positioning, vibration indication,delay rerecord
Built-in microphone/speaker
64KHZ
Build-in 32GB
Electronic shutter/1/2-1/2000s
Switchable lens filter, suitable for day and night use
Auto
Mini USB2.0
3.7V 4000mAh
-30℃～65℃
3.7V
Set a password on this machine for operation
