1.Getting Started

1.Each part on the device

1.1 Host structure diagram

1
2
3
4
5
1. Record button
3. Confirm/Playback button
5. Down/white light button
7. Intercom key
9. USB interface
11. Indicator
13. Speaker
15. Flashlight
17. Night vision light
19. Laser positioning light
6
7
8
9
10
15
16
13
17
18
14
2. Record/Menu button
4. Up/Night vision button
6. Camera button
8. Reset hole
10.Power on/off/Back
12. Intercom/base charging interface
14. Display
16. Lens
18. Microphone
1
11 12
19
