To Clean The Product; Technical Data - Meec Tools 031277 Bedienungsanleitung

Caution! Do not use force when you install the bat-
tery. If it is not easy to attach, it is not correctly aligned.
● Push the battery into the battery port of the product
until a click is heard.
3.2 To operate the product
1
Push the power button to start the product. The
product starts in high brightness mode.
2
To select brightness mode, push the mode button.
3
To stop the product, push the power button.
3.3 To adjust the angle of the
product
1
Loosen the angle adjustment screw.
2
Turn the handle of the product to the applicable
position.
3
Tighten the angle adjustment screw.
3.4 To attach the product to a hook
or a tripod
Warning! Make sure that the product hangs stable
to prevent injuries and damage to the product.
3.4.1 To hang the product on the hook
Figure 2
● Fold out the hook and hang the product horizontally.
3.4.2 To hang the product on the keyhole
Figure 3
1
Attach a screw or nail with a head diameter of 7–10
mm at the applicable position on the wall.
Note! Make sure that the distance between the head of
the screw or nail and the wall is approximately 10 mm.
2
Hang the product with the screw or nail through
the keyhole of the base plate.
3.4.3 To hang the product on the toothed
recess
Figure 4
1
Attach a screw or nail with a head diameter of 7–10
mm at the applicable position on the wall.
Note! Make sure that the distance between the head of
the screw or nail and the wall is approximately 10 mm.
2
Hang the product with the screw or nail through
the toothed recess of the base plate.
3.4.4 To install the product on a tripod
Figure 5
● Install a tripod to the 1/4'' or the 5/8'' thread on the rear
of the base plate.
4 Storage
● If the product is not going to be used for a long period
of time, remove the battery and keep the product in a
clean and dry place, where children and pets do not
have access to it.
5 Maintenance
5.1

To clean the product

Warning! Stop the product and remove the battery
before you clean the product.
Warning! Do not clean the product with water to
prevent the risk of short circuit.
Caution! Do not clean the product with abrasive
detergents or solvents to prevent damage to the product.
● Clean the product with a soft and dry cloth.
6 Discard
● Make sure that you follow local regulations when you
discard the product. Do not burn the product.
7

Technical data

Specification
Voltage
Power
Luminous flux
Color temperature
Dimensions (LxWxH)
Weight without battery
EN
SV
NO
DA
PL
DE
FI
FR
NL
Value
18 V
20 W
1000/2000 lm
5700 K
25 x 18 x 25 cm
1040 g
7
