Helios easyControls 3.0 Schnittstellenbeschreibung Seite 11

Functional Description
Ad-
dress
8194
8195
8196
8197
8212
8213
20487
20488
20490
20491
20499
20500
20501
20502
20505
20506
20507
20508
20511
20512
20513
20514
20537
20543
20544
20545
20546
20547
20548
20551
21766
21767
21772
NOTE
easyControls 3.0-Modbus RTU
Variable name R/
RW
GW_ADDRESS_1 R
GW_ADDRESS_2 R
MASK_ADDRESS_1 R
MASK_ADDRESS_2 R
IP_ADDRESS_1 R
IP_ADDRESS_2 R
CUSTOM_EXTR_FAN R/W
CUSTOM_SUPP_FAN R/W
RH_BASIC_LEVEL R/W
CO2_THRESHOLD R/W
AWAY_RH_CTRL_EN- R/W
ABLED
AWAY_CO2_CTRL_EN- R/W
ABLED
AWAY_SPEED_SET- R/W
TING
AWAY_AIR_TEMP_TAR- R/W
GET
HOME_RH_CTRL_EN- R/W
ABLED
HOME_CO2_CTRL_ R/W
ENABLED
HOME_SPEED_SET- R/W
TING
HOME_AIR_TEMP_ R/W
TARGET
BOOST_RH_CTRL_EN- R/W
ABLED
BOOST_CO2_CTRL_ R/W
ENABLED
BOOST_SPEED_SET- R/W
TING
BOOST_AIR_TEMP_ R/W
TARGET
FILTER_CHANGE_IN- R
TERVAL
RH_LEVEL_MODE R/W
BOOST_TIME R/W
CUSTOM_TIME R/W
FILTER_CHANGED_ R/W
DAY
FILTER_CHANGED_ R/W
MONTH
FILTER_CHANGED_ R/W
YEAR
PARTIAL_BYPASS R/W
BOOST_TIMER_EN- R/W
ABLED
CUSTOM_TIMER_EN- R/W
ABLED
EXTRA_TIMER_EN- R/W
ABLED
cK = CentiKelvin
0 degree Celsius = 27315 CentiKelvin = 273,15 Kelvin, Temp� in Kelvin = x Grad Celcius + 273,15
Temp� in CentiKelvin = x Grad Celsius *100 + 27315
10 degree Celsius = 28315 CentiKelvin = 283,15 Kelvin
Range of Type
validity
min max
0 65535
0 65535
0 65535
0 65535
0 65535
0 65535
0 100 %
0 100 %
0 65535 %
500 2000 PPM
0 1
0 1
0 100 %
27815 29815 cK
0 1
0 1
0 100 %
27815 29815 cK
0 1
0 1
0 100 %
27815 29815 cK
30 365 days
0 1
1 65535 min
1 65535 min
1 31 days
1 12 months
0 99 years
0 2 16bit value
0 1
0 1
0 1
3
Description
Gateway address (0xAABB)
Gateway address (0xCCDD)
Mask (0xAABB)
Mask(0xCCDD)
IP address first two bytes (0xAABB)
IP address last two bytes (0xCCDD)
Extract fan speed individual
Supply fan speed individual
RH basic level, 65535 = not calculated
CO2 threshold
RH control in use, away [False, True]
CO2 control in use, away [False, True]
Fan speed at away state
Supply air target temp at away state
RH control in use, home [False, True]
CO2 control in use, home [False, True]
Fan speed at home state
Supply air target temp at home state
RH control in use, boost [False, True]
CO2 control in use, boost [False, True]
Fan speed at boost state
Supply air target temp at boost state
Interval for filter change indicator (reload
value)
[0 = Automatic level update, 1 = Manual]
Boost timer load value
Individual timer load value
Last filter change date
Last filter change date
Last filter change date
Partial bypass state
[None, summer, always]
Boost timer enabled [off, on]
Individual timer enabled [off, on]
Timer configurable input activated
[off, on]
EN
