Helios easyControls 3.0 Schnittstellenbeschreibung Seite 10

Functional Description
EN
2�1�5 Unit addresses
External Modbus (Master): 19200-8-E-1 ventilation unit (Slave): 1
easyControls 3.0-Modbus RTU
Ad- Variable name
dress
4353 FAN_SPEED
4354 TEMP_EXTRACT_AIR
4355 TEMP_EXHAUST_AIR
4356 TEMP_OUTDOOR_AIR
4358 TEMP_SUPPLY_AIR
4363 RH_VALUE
4364 CO2_VALUE
4369 MULTISENSOR_TEMP
4370 MULTISENSOR_RH
4373 RH_SENSOR_0
4374 RH_SENSOR_1
4375 RH_SENSOR_2
4376 RH_SENSOR_3
4377 RH_SENSOR_4
4378 RH_SENSOR_5
4379 CO2_SENSOR_0
4380 CO2_SENSOR_1
4381 CO2_SENSOR_2
4382 CO2_SENSOR_3
4383 CO2_SENSOR_4
4384 CO2_SENSOR_5
4389 TEMP_OPTIONAL
4609 STATE
4610 MODE
4612 BOOST_TIMER
4613 CUSTOM_TIMER
4615 WEEKLY_TIMER_EN-
ABLED
4616 CELL_STATE
4621 LIMP_MODE
4849 MINUTE
4850 HOUR
4851 DAY
4852 MONTH
4853 YEAR
4854 WEEKDAY
R/ Range of Type
RW validity
min max
R 0 100 %
R 21000 33224 cK
R 21000 33224 cK
R 21000 33224 cK
R 21000 33224 cK
R 0 100 RH%
R 0 10000 PPM
R 0 65535 12BIT
R 0 65535 12BIT
R 0 65535 RH%
R 0 65535 RH%
R 0 65535 RH%
R 0 65535 RH%
R 0 65535 RH%
R 0 65535 RH%
R 0 65535 PPM
R 0 65535 PPM
R 0 65535 PPM
R 0 65535 PPM
R 0 65535 PPM
R 0 65535 PPM
R 20000 33224 cK
R/W 0 1
R/W 0 7
R/W 0 65535 MIN
R/W 0 65535 MIN
R/W 0 1
R 0 3
R 0 1
R/W 0 59 MINUTES
R/W 0 23 HOURS
R/W 1 31 DAYS
R/W 1 12 MONTHS
R/W 0 99 YEARS
R 1 7 WEEKDAY
2
Description
Current fan speed
Temperature, extract, cell input
Temperature, extract, cell output
Temperature, supply, cell input
Temperature, supply, heater output
RH value, highest measurement read, 0 =
No sensor
CO2 value, highest measurement read, 0
= No sensor
Temperature from internal sensor
Humidity from internal sensor
RH value from sensor 0, 65535 = No
sensor
RH value from sensor 1, 65535 = No
sensor
RH value from sensor 2, 65535 = No
sensor
RH value from sensor 3, 65535 = No
sensor
RH value from sensor 4, 65535 = No
sensor
RH value from sensor 5, 65535 = No
sensor
CO2 value from sensor 0, 65535 = No
sensor
CO2 value from sensor 1, 65535 = No
sensor
CO2 value from sensor 2, 65535 = No
sensor
CO2 value from sensor 3, 65535 = No
sensor
CO2 value from sensor 4, 65535 = No
sensor
CO2 value from sensor 5, 65535 = No
sensor
Optional external temperature sensor
General state [0 = Home, 1 = Away]
Override state [0 = normal, 5 = off]
Remaining time Timer boost ventilation
(note data point 21766, 65535 = Duration
active)
Remaining time Timer individual mode
(note data point 21767, 65535 = Duration
active)
Weekly timer state [0 = off, 1 = on]
Cell state [0 = heat recovery, 1 = cool re-
covery, 2 = bypass, 3 = defrosting]
Device fault active, device in limp mode
[off, on]
Minutes of the current time
Hours of the current time
Days of the current date
Months of the current date
Years of the current date
Weekday [Mon, Tue, Wed, ...]
