EDIFIER X5 Pro Bedienungsanleitung

True Wireless Noise Cancelling Earbuds
EN 1. Power ON/OFF
Open or close the case to power on/off.
2. First pairing
1. Once powered on, the earbuds will automatically enter Bluetooth
pairing mode.
2. Select "EDIFIER X5 Pro" from your device list to connect.
3. Pairing for new device
3s
1. Place the earbuds in the case and keep it open.
2. Press the button on the case for 3s.
3. Select "EDIFIER X5 Pro" from your device list to connect.
Note: For subsequent use, the earbuds will automatically connect to
the device used last time.
4. Reset/Left & Right Connection
x3
1. Place the earbuds in the case and keep it open.
2. Press the button on the case 3 times, white LED blinks until the
reset is complete, then the earbuds will automatically enter
Bluetooth pairing.
Note: This operation will clear pairing records, reconnect left & right
earbuds and restore factory setting.
5. Multipoint connection
①
②
3s
③
1. Pair device A with the earbuds manually and keep the earbuds in the
case;
2. Press the button on the case for 3s to re-enter Bluetooth pairing and
select "EDIFIER X5 Pro" in device B settings to connect.
3. Select "EDIFIER X5 Pro" again in device A settings to complete the
multipoint connection.
6. Controls
Note:
1. "x2" double press; "x3" triple press; "—" Press and hold.
2. Default sound control: High Noise Cancellation /
Wind Reduction / Ambient Sound.
3. Download EDIFIER ConneX App to customize more control
settings.
7. Charging
Use the included USB-C cable to connect to a power source for
charging.
Input: 5V 200mA (Earbuds)
Note: Make sure the eabuds and USB-C port is completely dry before
charging.
EN 18031-2:
Built
X5 Pro
Model: EDF200203
Manual
Bluetooth
EDIFIER X5 Pro
A
L
x2
x2
x2
x3
Bluetooth
EDIFIER X5 Pro
Bluetooth
EDIFIER X5 Pro
R
x2
x2
x2
x3
5V 1A (Charging Case)
Bluetooth
EDIFIER X5 Pro
A
B
