EDIFIER W820NB Plus Bedienungsanleitung

W820NB Plus
Wireless Over-ear Noise Cancelling Headphones
EN 1. Power ON/OFF
ON
OFF
Press and hold the power button to power on/off.
2. First pairing
1. Once powered on, the headphones will automatically enter Bluetooth
pairing mode.
2. Select "EDIFIER W820NB Plus" from your device list to connect.
3. Pairing for new device
1. In ON state, press and hold the "
to enter Bluetooth pairing mode.
2. Select "EDIFIER W820NB Plus" from your device list to connect.
Note: For subsequent use, the headphones will automatically connect to the device used last time.
4. Controls
● Call
● Music
● Mode
Note:
1. "x 1" Press, "x 2" Double press, "—" Press and hold.
2. Default sound control: High Noise Cancellation / Ambient Sound.
3. Download EDIFIER ConneX App to customize more control settings.
5. Multipoint connection
①
②
③
1. Pair device A with the headphones successfully.
2. Press and hold the "
pairing mode, and then select "EDIFIER W820NB Plus" in device B
settings to connect.
3. Select "EDIFIER W820NB Plus" again in device A settings to complete
the multipoint connection.
Note: For subsequent use, the headphones will automatically reconnect to the two devices used
last time.
6. Wired listening
Connect to the headphones via the included USB-C audio cable. Wired
listening will automatically disable Bluetooth mode.
7. Reset
1. In ON state, press "+" and ''-'' buttons for 5 seconds, and blue LED will
blink until the reset is complete.
2. Then the headphones will automatically enter Bluetooth pairing mode.
8. Charging
Connect the headphones to a power source via the USB-C cable for
charging.
Note: Make sure the USB-C port is completely dry before charging.
EN 18031-2:
Built
Model: EDF200220
Manual
1s
-
1s
-
x1
x1
x2
x1
x1
x2
x1
x1
x2
Bluetooth
EDIFIER W820NB Plus
A
" button for 3 seconds to re-enter Bluetooth
5s
x6
Bluetooth
EDIFIER W820NB Plus
Bluetooth
EDIFIER W820NB Plus
" button for about 3 seconds
Bluetooth
EDIFIER W820NB Plus
A
B
Input: 5 V 1 A
