EDIFIER W830NB Bedienungsanleitung

Wireless Over-Ear Headphones with Active Noise Cancellation
EN 1. Power ON/OFF
Press and hold the power button to power on/off.
2. First pairing
1. Once powered on, the headphones will automatically enter
Bluetooth pairing mode.
2. Select "EDIFIER W830NB" in your device setting to connect.
3. Pairing for new device
1. In ON state, press and hold the "
enter Bluetooth pairing mode.
2. Select "EDIFIER W830NB" in your device setting to connect.
Note: For subsequent use, the headphones will automatically connect to the device used last time.
4. Dual-device connection
①
②
③
Bluetooth
EDIFIER W830NB
1. Pair device A with the headphones successfully.
2. Press and hold the "
pairing mode, and then select "EDIFIER W830NB" in device B setting
to connect.
3. Select "EDIFIER W830NB" again in device A setting to connect, and the
dual-device connection is done.
Note: 1. Dual-device connection is disabled by default. Enable this function via the app.
2. For subsequent use, the headphones will automatically reconnect to the two devices used last time.
5. Charging
Connect the headphones to a power source via the USB-C cable for
charging.
Note: 1. Make sure the USB port is completely dry before charging.
2. When charging with a USB-C cable, the product is used as wired headphones and
Bluetooth functions are unavailable.
6. Controls
Call
●
x1
x1
x2
x2
Music
●
x1
x1
x1
Mode
●
x1
x2
－
Note:
1. "x 1" Press , "x 2" Double press , "—" Press and hold.
2. Default sound control: High Noise Cancellation / Ambient Sound / Noise Cancellation Off.
3. Download EDIFIER ConneX App for more customizable control settings.
7. Reset
In ON state, press "+" and ''-'' buttons for 5s to finish reset, then
headphones will automatically enter Bluetooth pairing mode if successful.
8. Wired listening
Connect to the headphones via the USB-C cable. Wired listening will
automatically disable Bluetooth mode.
W830NB
Model: EDF200163
Manual
3s
A
" button for 3 seconds to re-enter Bluetooth
1s
ON -
OFF - 1s
Bluetooth
EDIFIER W830NB
3s
Bluetooth
EDIFIER W830NB
" button for about 3 seconds to
Bluetooth
EDIFIER W830NB
x6
A
B
Input: 5V 1A
5s
