1. Control Panel

2. First Use Notes:

If the standing desk is assembled and used for the first time, or if the displayed height doesn't match the actual height of the adjustable legs, or if the height has been changed after reassembly,

a reset is required. Otherwise, the standing desk can be used directly with the factory settings.

3. Reset Operation:

Press and hold the "↓" button for 5 seconds until the adjustable legs stop. The controller will display "rES" to indicate that the reset has begun. Do not release the "↓" button. The adjustable legs will

slowly lower to the lowest position and retract slightly. Release the "↓" button to complete the reset operation.

If an unexpected situation occurs during the reset process, you can release the "↓" button at any time to stop the adjustable legs. After the reset is stopped, you must repeat the reset operation

until it is successful before performing any other operations.

4. Up and Down Operation:

Press and hold the "↑" or "↓" button on the controller to raise or lower the standing desk. Release the button to stop.

5. Memory Function:

While the adjustable legs are in a stopped state, press and hold any of the "M1", "M2", "M3", or "M" buttons for 5 seconds. The controller will display "S-X" (X is the button number), indicating that the

current height is saved to the corresponding button.

After saving a height, simply press any of the "M1", "M2", "M3", or "M" buttons briefly, and the standing desk will automatically adjust to the saved height. While adjusting to a saved height, press

any button to stop.

6. Child Lock:

Press and hold the "↑" and "↓" buttons simultaneously for 5 seconds. When the controller displays "Loc", the system is locked and cannot be operated. To unlock the system while it is locked, press

and hold the "↑" and "↓" buttons simultaneously for 5 seconds until the controller displays a normal number instead of "Loc".

7. Energy Saving Mode:

The controller will turn off the screen if there is no button operation within 60 seconds. Press any button to exit the energy-saving mode.

8. Charging Function:

The controller is equipped with a USB-C port. It automatically detects your device's charging protocol and supports the following outputs:

5V 3A, 9V 2.22A, and 12V 1.67A

9. Menu Options:

Press and hold the "M" button for 10 seconds to enter the menu. The menu content will flash on the display. There are 7 menu options:

① Minimum Height Setting

② Maximum Height Setting

③ Thickness of the Tabletop

④ Upward Anti-Collision Sensitivity

⑤ Downward Anti-Collision Sensitivity

⑥ Tilt Sensor Sensitivity

⑦ Display Unit Setting

How to Operate:

Step 1: Briefly press the "M" button to navigate through the menu pages. Use the "↑" and "↓" buttons to change the menu contents. (Quickly set the parameters of ① and ② by pressing and holding

the "↑" or "↓" button.)

Step 2: After adjusting the parameters, press and hold the "M" button. A progress bar will appear and scroll to the right. Once the progress bar has finished loading, "SUS" will appear on the

screen, indicating that the parameter adjustment has been saved, and the controller will automatically exit the menu. If "FAL" appears on the screen, the setting fails. Repeat the above steps to

try again.

The menu mode is automatically exited if no operation is performed within 10 seconds.
