REMOTE CONTROL DIAGRAM
Forward Knob switch
MANUAL
speed
emergency
brake
code key
backward
low speed
middle speed
high speed
Remote control first. Remote control first When the
rotary switch is turned to "REMOTE", it indicates
remote control status and cannot be pedal. At this
time, the three indicator lights are constantly on.
Operation Manual:
Take out the remote control, Open the battery compartment on the
back of the remote control and add two AAA LRO3 alkaline batteries.
Pay attention to the polarity of the batteries. When the alignment light
and speed indicator light up, it indicates that the battery installed is
correct. This product does not provide dry batteries.
<Button Description >
1)Long press the forward and backward keys for 2-4 seconds, and the
low-speed LED light flashes. Turn on the car power, the low-speed
LED light flashes continuously until it stays on, and then the frequency
binding is successful. If frequency binding fails (low speed LED
flashing), remove the battery and repeat the steps.
18
Warning
REMOTE
Only used
by adults
turn left turn right
P: Press to brake.
S: Speed: press to change speed(low, middle and high speed).
Forward Backward
Turn Left Turn Right
2) Brake button: Press it to stop moving; press it again to move.
3) Speed selection key and speed indication: Used to select speed of
the car. Press the key once to switch the speed once. 3 speeds are
cyclically switched, and the switching sequence is: low-medium-high.
The speed indicator is arranged from top to bottom on the remote
control: high-speed lamp, medium-speed lamp, low-speed lamp; when
switching to one speed, the corresponding indicator lamp will light up.
Note: The speed grade changes only when moving forward.
4) Forward/backward keys: Used for forward and backward movement
control. When one of the keys is pressed, the moving speed will
slowly increase to reach the set speed level. Therefore, children will
not have a sudden impact.
5) Left tum/right tum key: Used for left and right direction control.
6) Knob switch: Control pure manual and remote control mode. When
the arrow in the middle of the remote control knob points to
"REMOTE", it indicates the remote control status and cannot be
manually operated. At this time, the three indicator lights are constant-
ly on/When the arrow in the middle of the remote control knob points
to "Manual", it indicates manual status and cannot be remotely
controlled. At this time, the three indicator lights flash.
Note: without operation after 10 seconds, indication light will off into
power saving mode.
Knob Switch
