FIG.17
9. Retighten the brake cable nut
slightly with a 10mm wrench.
Refer to page 7 for proper
adjustment.
Adjusting the Strap
Tools required: 4mm hex wrench, two 13mm wrenches, 10mm wrench and a Phillips
screwdriver.
FIG.19
1. With a 4mm hex wrench, remove
the three screws on the protective
cover on both sides of the scooter.
FIG.18
10.Reinstall the side covers with a
4mm Allen key. Do not
overtighten the screws.
FIG.20
2. Loosen the brake arm with a Phillips
screwdriver and 8mm wrench. Using
two 13mm wrenches, loosen the
wheel nuts on the rear axle.
13
