3.3 Example Configuration
Operator terminal
RS422
Controller
The stations are configured according to the table below. The settings made are
indicated by the corresponding LEDs. For configuration instructions, see
chapter 4 Setup.
Station
Keyboard
number
Station 1 1*
Station 2 2 (F16 + F2) 38,400 bps*
* Default setting
If two additional extended keyboards are added, configure the station numbers
3 and 4 in the same way as Station 2.
Beijer Electronics, MAEN827B
X-Key 16, station 1
RS232C (CAB5)
Communication
speed
38,400 bps*
X-Key 16, station 2
RS485
Communication
port
RS232C*
RS485 (F16 + F15) Disabled*
Configuration
Pass through
messages
Enabled (F16 + F7)
9
