Physical
Dimensions......................... 77 x 129 x 24 mm(3" x 5" x 1")
Weight .............................................
Terminals ..................................4 mm sockets {gold plated}
Case ....................................................... High impact ABS
Relative Humidity.................................................... 0 to 90%
Safety
This symbol, on the loop calibrator, indicates that
the user should refer to the user guide or manual.
Batteries
•
Remove batteries from the loop calibrator immediately
when discharged and before storage.
•
Dispose of batteries in accordance with local regulations
and battery manufacturers' instructions.
•
When storing and transporting batteries make sure they
cannot be short circuited.
Power Supply
The power supply for this loop calibrator can be the internal
non-rechargeable batteries or the external Universal power
supply unit (see accessories).
Battery life
The display shows
Battery Replacement
•
Unscrew and remove the securing screw from the
battery panel.
•
Replace the batteries, check the polarity of the batteries.
•
Refit and secure the battery panel.
Accessories
Assy 305 Test lead set
191-129
Power supply, Universal, 100-240 V a.c. 47-63Hz
38016
Carrying case
38023
Protective rubber boot
K317 Issue No. 1
> 75 hours in measure mode
> 18 hours at 12 mA (source mode)
with low battery power.
2
275 grams (0.6 lbs)
