UPS III Loop Calibrators
Introduction
The Druck UPS III Series of loop calibrators can supply
power (source mode) and produce readings
(measure mode) to perform field calibrations on 2-
wire devices. The set-up menu enables the user to
"source" or "measure" in either voltage or current and
to perform continuity tests. These user instructions
include the operation, safety instructions and
installation requirements for loop calibrators.
Specifications
Accuracy
Values in table below includes temperature effects 17°C to 27°C
Outside these limits ..................
Calibration Reference................
Mode
Source mA
Source mA +
24V
Measure mA 0 to 24 mA* 0.01% rdg + 2 lsd V-max. 75V
Measure mA
+ 24V
Measure V
Continuity
* Resolution 0.001
** Audio + visual
Operating Temperature...... -10°C to 50°C (-14°F to 122°F)
Storage Temperature.........
This loop calibrator meets the essential protection
requirements of the relevant EEC directives.
Conforms to ......... EN61010, EN 61326-1(1997)+ A1(1998)
Electrical Power Supply
....................................
Universal power supply {see accessories}
Range
0 to 24 mA* 0.01% rdg + 2 lsd V-max. 75V
0 to 24 mA* 0.01% rdg + 2 lsd R-max 1k
0 to 24 mA* 0.01% rdg + 2 lsd R-measure
0 to 60V*
<100Ω **
4 x 1.5 V alkaline size AA or
1
0.003%/°C(0.0015%/F°)
22°C ±1°C/RH45%±15%
Accuracy
0.02% rdg + 4 lsd R-measure
-
lsd least significant digits
rdg reading
-20°C to 70°C (-4°F to 158°F)
Remarks
at 20 mA
Ω
15
Ω
1M
1 mA
K317 Issue No. 1
