If there is no router available, then the Z21 pro LINK can also be operated in limited host mode.
Note: Please observe that updates and the web interface only work in client mode, i.e. In connection with a Z21 router.
You can fi nd further information on use and confi guration on our website www.z21.eu in the 10838 – Z21 pro LINK section. Because
the Z21 pro LINK functions are continuously being extended through the software, you can always procure the latest updates or infor-
mation from the Z21 website https://www.z21.eu/de/produkte/z21-pro-link.

3. Connecting the Z21 pro LINK

The connection of the Z21 pro LINK to a zLink-compatible terminal device, e.g. the Z21 booster or Z21 decoder, is carried out using the
enclosed zLink cable.
Note: Only use the original Z21 zLink cable. Other cables cause disruptions, or in the worst case can lead to the destruction of
your hardware.

3.1 Power supply

The Z21 pro LINK can also be supplied from the zLink-compatible device.
Alternatively, the Z21 pro LINK can also be supplied via a USB power port. In this way, the Z21 pro LINK can also supply the connected,
zLink-compatible device. To do this, use the 10859 - USB 5 Watt switching power supply.
You can fi nd a list of all compatible devices on: https://www.z21.eu/de/produkte/z21-pro-link
