Samsung SEK-2000 Evolution Kit Kurzanleitung Seite 4

4. Insert the Evolution Kit into the two slots as shown in the diagram below,
1
1 1
5. To make sure the Evolution Kit attached securely, press it again, as shown by the figure below.
6. Connect a wired network to the TV
- 2012 TV: To use a wired network on a TV that has an Evolution
Kit attached, disconnect the LAN cable from the TV, and then
connect it to the Kit using the LAN Cable Adapter.
1 2
English-4
and then attach to the TV.
2
2
- 2013 TV: To use a wired network, connect the LAN cable
to the TV.
LA N
