7
8
10
13
6*
Front panel connections
6. Analogue audio - line in
Connect an analogue audio input here using a stereo 3.5mm jack cable such as
QED Performance J2J. A green LED means this input is active.
Front panel controls
7. Standby indicator
Illuminates red to indicate the unit has entered standby.
8. Standby/on key
Touch here to toggle the unit on or off.
9. Volume up key
Touch here to increase the volume.
10. Volume down key
Touch here to decrease the volume.
11. Source key
Touch here to toggle between Bluetooth and line-in sources.
12. Volume position array
Provides a visual indication of current volume setting. A single pulsing LED means
mute. Auto dims after 10s. Touch here to toggle play/pause when in Bluetooth
mode.
13. Indicator LEDs
Blue = Bluetooth, Green = Analogue In
* Not present on E50w. Both models include line in socket on rear.
E50 Front View
5
9
12
11
