English
Connect Your PoE Switch
Powered Device (PD)
IP Camera AP
PC
Internet
Router/Gateway
LAN Port WAN Port
DC Power Supply
Note:
1. The PoE ports can also connect to non-PoE devices, but only transmit data.
2. The PoE ports shall not be used to charge lithium batteries or devices supplied by lithium batteries.
3. PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will
vary as a result of client limitations and environmental factors.
4
