Powerplus HYENA Kurzanleitung

Solar | Dynamo | USB powered DAB+/FM radio
Powerbank | Flashlight | Reading Light | SOS Alarm | Clock
9
1 Speaker 5 Volume
2 Charging indicator 6 Menu / Info button 10 SOS alarm
3 Display screen 7 Select / Scan button 11 USB output
4 ON/OFF switch | mode selection 8 Previous / Next button 12 USB Type C input
16
15
Activate the battery
This radio uses an 18650 rechargeable Li-Ion battery (3.7V | 2.500 mAh).
To activate the battery, release the battery insulation tab from the backside battery door.
When the radio is not used for a long time, release the 2 screws at the battery door and
take out the battery. When you replace the battery please ensure you replace with a battery with
the same specifications. Beware of placing the battery with the right polarity when replacing.
Make sure to charge the radio at least once a month to maintain the battery.
In case the 18650 battery is running flat and remaining voltage becomes below a critical voltage,
the battery may be damaged.
Charge the radio immediately by USB, solar or dynamo when the battery status symbol shows
that the battery is empty.
Charging the device
1) By USB
Lift up the rubber cap to access the charging in port.
Connect the supplied Type C USB charging cable to the type C USB
charging input (12)
Connect the other end of the USB charging cable to an USB charger,
powerbank or USB interface of your computer (not included).
During charging, the charging indicator (2) will flash to indicate the
device is charging. When the battery is fully charged, the indicator
will illuminate constantly (stop flashing).
It takes around 4-5 hours for fully charge the battery.
When the charging indicator (2) is on (not flashing anymore) during USB charging, this means the battery is fully loaded and the battery
will not further be charged by the built-in overcharge protection. Disconnect the charging cable after the battery is fully charged.
Receipt of the DAB+ signal can be affected by USB charging. Digital signals of DAB+ are very sensitive and charging by USB
generates a small electro-magnetic field with can affect the sensitive signal, depending on the signalstrength of the DAB+ station.
In case of non-receipt or signal disturbance during USB charging, select another DAB+ station or find the required station in FM mode.
2) By dynamo manual power generation
Take out the dynamo arm (16) and rotate the arm at an even speed of around 2 revolutions
per second (120 revolutions per minute). This will charge the Li-Ion battery with the
highest efficiency at charging current of around 400mA. You can charge in both directions.
Over high rotation speed will not increase the power generation.
Do not over high rotate, as it may damage the device.
During charging, the charging indicator (2) will illuminate to indicate the device is charging.
3) By solar power
Place the solar panel (13) towards the sun.
The charging indicator (2) will illuminate during charging.
Charging by solar power is the most efficient in full sun condition. During cloudy weather
the solar panel only can provide a limited charge. To charge battery from empty to full
takes around 80 hours of solar charging in full sun conditions.
Discharge protection
When the battery is overloaded or short-circuited, the product functions will stop automatically.
When the battery power is lower than 2.75V, the product functions will also stop automatically.
Radio function
Switching on and off
Press and hold the ON/OFF button (4) until the radio switches on. The display (3) will show 'Welcome to Digital Radio'
By pressing the ON/OFF | mode selection button (4) you can switch between FM and DAB+ mode.
To switch the device to standby mode, press and hold the ON/OFF | mode selection button (4) until display (3) will show 'Standby'.
The actual time and date and battery status indicator will appear on the display.
To switch to radio, press the ON/OFF | mode selection button (4) once to switch to radio function again.
To switch the device off, press and hold the ON/OFF | mode selection button (4) until display shows 'Bye Bye'.
11
After 15 minutes no signal reception, the Hyena will automatically switch to standby mode.
10
DAB mode
12
Take out the telescopic antenna (15) to optimise the receipt of the radio signals.
Switch the device on and select DAB mode by using the ON/OFF | mode selection button.
The selected mode (DAB or FM) will appear for about 3 seconds in the display (3) when pushing the selection button (4) once.
For first time DAB mode will be used, the device will make a quick scan to search for available DAB+ radio stations. Please leave this
to complete the scanning process.
A complete list of stations scanned can be found in the system menu under "Station List".
9 LED lamp
Press the PREVIOUS and NEXT buttons (8) to select the desired radio station.
Press the SCAN button (7) to make a new scan for available DAB+ stations.
FM mode
Press the ON/OFF | mode selection button (4) until FM appears in the display (3).
Press and hold the PREVIOUS or NEXT button (8) until the desired radio station is found.
13 Solar panel | lift up for reading light
Memory preset radio stations
14 LED Flashlight switch
15 Telescopic antenna
You can store up to 40 radiostations in the memory in both DAB+ and FM mode.
16 Dynamo arm
A stored memory station can be erased by storing another radiostation under this preset number.
Tune to the desired radiostation in DAB+ or FM mode. Press and hold the MENU | INFO button 6) to enter the menu. Press the PREVIOUS
or NEXT button (8) until <Preset Store> appears in the display (3). Press the SELECT | SCAN button once to select this menu option
and use the PREVIOUS or NEXT buttons (8) to select the required preset memory number. After you selected the required number, press
SELECT | SCAN button (7) to confirm.
To find a preset memory station, press and hold the MENU | INFO button (6) to enter into the menu. Use the PREVIOUS | NEXT buttons (8)
to go to <Preset Recall> in the display. Press the SELECT | SCAN button (7) to enter the list and with the PREVIOUS | NEXT buttons (8)
you can see the stored radiostations under the preset numbers. Press the SELECT \ SCAN button (7) once you find the desired preset
memory station.
Setting the alarm
In standby mode, press and hold the MENU | INFO button (6) and <System> will appear in the display (3). Select the system options by
pressing the SELECT | SCAN button (7) and with the PREVIOUS | NEXT button select <Alarm> with the SELECT | SCAN button (7).
You then can select using the PREVIOUS | NEXT buttons (8) and SELECT | SCAN button (7) to confirm selections:
• Alarm 1 or Alarm 2
• Alarm On and Alarm Off
• Alarm time setting
• Duration of alarm
• Source of alarm (buzzer, DAB+ of FM)
• Interval of alarm (once, daily, weekends, weekdays)
• Date (if you select "once" above)
• Volume of source
Display shows 'Alarm saved' after you succesfully saved an alarm.
You can set 2 different alarm settings.
The display (3) shows with a bell icon which alarm is set (1 or 2) and if both alarms are set, it shows 2 bell icons.
Snooze function
When alarm sound, you can snooze it for 9 minutes by pressing the SELECT | SCAN button (7). The display will show the countdown
of the snoozing time when the next alarm will sound.
Press the ON/OFF | mode selection button (4) to switch the alarm off during the alarm or during snoozing.
Adjust the volume
Use the volume down and up buttons (5) to decrease or increase the volume.
Flashlight
Press the flashlight ON/OFF button (14) to activate th3 3 different flashlight modes
Reading light
Behind the solar panel a 12 LED reading light is integrated.
Lift up the solar panel carefully from the backside to active the reading light.
SOS alarm
Press the SOS button (10) to activate the buzzer alarm with flashing LED flashlight.
Press again to stop the SOS alarm.
Language setting
Press and hold the MENU | INFO button (6) and <System> will appear on the display.
Press the SELECT | SCAN button (7) to enter the system setting.
Select <Language> and press the SELECT | SCAN button (7) to confirm.
You can choose between English | German | Italian | French language.
Sleep function
Press and hold the MENU | INFO button (6) and <System> will appear on the display. Press the SELECT | SCAN button (7) to enter the
system setting. Select <Sleep> and press the SELECT | SCAN button (7) to confirm. You can select between sleep off, 15 minutes, 30
minutes, 45 minutes, 60 minutes and 90 minutes.
Factory reset
Press and hold the MENU | INFO button (6) and <System> will appear on the display. Press the SELECT | SCAN button (7) to enter the
system setting. Select <Factory Reset>. You can select Yes or No for factory reset.
Powerbank function
Lift up the rubber cap to access the USB charging out port.
Connect the USB charging cable to your device and the USB outport
of the Hyena. The charging of your mobile device will automatically start.
The charging indicator (2) will illuminate blue colour during charging of
your mobile device.
Disconnect the USB charging cable once your mobile device is
fully charged.
The Hyena comes with a 2.500 mAh battery, so the charging capacity
is limited.
PRECAUTIONS:
1. Do not expose the unit to extreme temperature nor high humidity to ensure normal functioning for a long lifetime.
For instances, never place the unit in bathing areas nor around stoves and radiators.
2. If you find the unit is not working properly, please take it to your nearest services center. Do not attempt to repair by yourself.
WARNING:
To prevent fire or shock hazard, do not expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet, refer to
service agent or qualified engineer only.
Trouble shooting
• No radio signal
Be sure the antenna is out and be sure that you are in a position where radio-signals can be received. If you are in a building with steel
frames, signal receipt reception can be poor or even none.
• Radio stops playing
Battery level is low. Recharge the battery.
Be sure that the battery is placed in the right polarity.
• Buttons are not working or do different function
Turn the radio off and turn it on again to check if functions are recovered.
• Powerbank does not work
Be sure that your device is USB 5V DC rechargeable.
Some charging protocols (like Apple devices) are very special, which may lead that they will not accept charger for different sources.
Battery replacement
This radio is equiped with a rechargeable Li-Ion battery type 18650 (consumerversion).
After lifetime of the battery, the battery can simply be replaced by a new battery.
After lifetime of the battery and/or product, please deliver to a recycling point for recycling.
Product recycling
After lifetime of the product, bring the product to a collection point for recycling.
Technical details
Frequency range DAB+: 174-240 Mhz
FM: 87.5 - 108 Mhz
Speaker 40mm, 8 ohm dynamic, 1.0W RMS
Lithium-Ion battery 18650 | 3.6V | 2.500 mAh
Charging in USB Type C input, 1.000 mA max.
Dynamo charger 400 mA max.
Solar charging 40mA max.
Powerbank output 1.000 mA max.
Power consumption About 280mAh for speaker
About 160mAh for flashlight
About 160mAh for reading light
About 240mAh for SOS alarm
Operating time solar 1 hour of solar charging in full sun conditions: • 8 minutes radio time
• 15 minutes of flashlight / reading light
• 10 minutes of SOS alarm
www.powerplus.nl
