Assembly
Checking the product and scope of
delivery
WARNING!
Risk of suffocation! There is a risk of
suffocation by ingestion or inhalation of
films. Keep the packaging film out of the
reach of children.
• Take the product and the accessories out of
the packaging.
• Check that the delivery is complete (see the
"Scope of delivery" section).
• Check whether the product or the accessories
are damaged.
• Do not use the product if it is damaged or
parts are missing. Contact the service centre
listed on the warranty card.
Assembly
CAUTION!
Do not connect the mains plug to the
mains socket before assembling the
product completely and checking the
proper condition.
• The product is intended for outdoor
use only. Place the product only in an
open area. Do not place the product
under low ceilings, keep it away from
heat sensitive and flammable objects.
Place the product such that it cannot
be accidentally touched.
• Do not install the product near
bathtubs, swimming pools, sinks or
similar areas where water is present.
• The product should not be covered to
prevent over-heating and risk of fire.
• The product should not be placed next
to a wall socket.
• The product should not be operated
without supervision, especially in case
of children or persons with hampered
physical abilities.
18
611626_Buch_DE_EN_FR_CZ_SI_HR.indb 18 611626_Buch_DE_EN_FR_CZ_SI_HR.indb 18
• Screw the column part 6 into the stand 7
(Fig. A).
• Guide the mains cable 8 through the stand
and the column part.
• The mains cable has to protrude at least 2
meters at the upper end of the column part.
(Fig. B).
• Insert the plastic holder A and the support
table 4 over the lower column part. (Fig. C).
• Insert the plastic holder B over the lower
column part.
• Fix the support table to the column by turning
the the plastic holder 5 (Fig. E, F).
• Screw the middle column part 3 to the lower
column part.
• Guide the mains cable through the middle
column part.
• Repeat this step and screw the upper column
part to the middle column part.
• Likewise guide the mains cable through the
upper column part. (Fig. G, H).
• Connect the mains cable to the plug on the
heater head C (Fig. I).
Use restore the plug provided to
additionally secure the connection.
• Fix the heater head 1 to the top of the
column using two M4*8 screws 9 (included
with the supply). (Fig. J, K).
• Pull the upper column part to the desired
height (max. about 225 cm) and fix it using
the fixing collar D (Fig. L).
• Loosen the fixing screw E and adjust the
support table to the desired height. (Fig. M).
• Fasten the mains cable to the two clamps on
the stand.
• Check the fixing and connections before
connecting the mains plug to a suitable
mains socket. (Fig. N).
