gent Homematic IP installation. Using existing or planned
switches and cabling reduces the cost of installation to a
minimum. The design, colour and finish of switches that
have already been installed does not change, since exist-
ing frames and rockers can continue to be used.
The dimming actuator enables dimming of
• normal incandescent lamps,
• high-voltage halogen lamps,
• low-voltage halogen lamps with electronic trans-
formers,
• dimmable energy-saving lamps (1) and
• dimmable LED lamps (2).
(3) The usable dimming range is usually extremely restricted.
(4) It is not guaranteed that the dimming behaviour will be performed correctly
for all types of LED lamps.
Device overview (see figure 1):
(A) system button (teach-in button and LED)
(B)
connecting terminal for N (neutral conductor)
(C) connecting terminal for L ( phase conductor)
(D)
connecting terminal for
Installation overview (see figure 2)
Function and device overview
(dimmed phase)
