Connect cables from Chassis
Connect everything to the motherboard
•
Front panel system header
•
USB connector/header
NOTE: Please refer to the manual(s) for more information:
Motherboard
Chassis
Connect cables from PSU
Install the graphics card
6
Power
+PWR_LED-
PWR_BTN
PIN 1
+HDD_LED-
RESET
NOTE: Please note that power connection is required for
•
Front panel audio header
Connect cables from PSU
•
SATA
NOTE: Please refer to the manual(s) for
more information:
selected models.
Please refer to the manual(s) for more information:
Motherboard
Chassis
Motherboard
Graphics Card
