EDIFIER NeoBuds Pro 3 Bedienungsanleitung

NeoBuds Pro 3
True Wireless Noise Cancelling Earbuds
EN 1. Power ON/OFF
Open or close the case to power on/off.
2. First pairing
1. Once powered on, the earbuds will automatically enter Bluetooth
pairing mode. LEDs will be lit one by one from left to right in a
circulating pattern.
2. Select "EDIFIER NeoBuds Pro 3" from your device list to connect.
3. Pairing for new device
1. Place the earbuds in the case and keep it open.
2. Press and hold the button on the case for 3s. LEDs will be lit one by
one from left to right in a circulating pattern.
3. Select "EDIFIER NeoBuds Pro 3" in your device settings to connect.
Note: For subsequent use, the earbuds will automatically connect to the
device used last time.
4. Multipoint connection
①
②
③
1. Pair device A with the earbuds manually and keep the earbuds in
the case.
2. Re-enter Bluetooth pairing and select "EDIFIER NeoBuds Pro 3"
in device B settings to connect.
3. Select "EDIFIER NeoBuds Pro 3" again in device A settings to
complete the multipoint connection.
5. Reset/Left & Right Connection
1. Place the earbuds in the case and keep it open.
2. Press the button on the case 3 times. LEDs will be lit one by one
from sides to center in a circulating pattern and then blink twice if
successful.
Note: This operation will clear pairing records, reconnect left & right
earbuds and restore factory settings.
6. Charging
Use the included USB-C cable to connect to a power source for charging.
Input: 5 V 200 mA (Earbuds)
Note: Make sure the earbuds and the USB-C port are completely dry
before charging.
7. Controls
Call
●
Music
●
Mode
●
Note:
1. "x1" Press; "x2" Double press; "x3" Triple press; "—" Press and hold.
2. Default sound control: High noise cancellation / Ambient sound.
3. Download EDIFIER ConneX App to customize more control settings.
EN 18031-2:
Built-in microphones for hands-free smartphone calls.
Built-in infrared proximity sensor for wearing detection.
Manual
Indicator light
Bluetooth
EDIFIER NeoBuds Pro 3
A
L
x1
x1
x2
L
x1
x2
x3
L
3s
3s
5 V 1 A (Charging case)
R
x1
x1
x2
R
x1
x2
x3
R
Bluetooth
EDIFIER NeoBuds Pro 3
Bluetooth
EDIFIER NeoBuds Pro 3
Bluetooth
EDIFIER NeoBuds Pro 3
A
B
x3
