Absima First Step Performance Bedienungsanleitung Seite 10

(1) Connect the USB charger to a power socket (Fig. 4). The red LED
lights up. Now connect the battery to the USB charger (Fig. 5). The
green LEDs start to flash. The charging process is complete as soon as
the green LED lights up constantly.
(Fig. 5)
11.1V
(3) Insert the fully charged battery into the battery compartment and
connect the cables correctly (Fig. 7).
(Fig. 7)
(1) Do not use a power source for the USB
charger with more than 2.4A
(2) If the input current exceeds 2.4A, a protection mode is
protection mode is automatically activated and all
LEDs go out.
Transmitter instructions
(Fig. 4)
A. Power switch
B. Steering trim
C. Gas trim
(Zero speed to
full speed)
- 8 -
(2) Loosen the Velcro strap of the battery on the
housing and remove the battery (Fig. 6)
(Fig. 6)
(4) Reinsert the battery and tighten the Velcro tape (Fig. 8)
(Fig. 8)
11.1V
1) Forward
2) Brake
3) Left
4) Right
5) Backwards
