Bailey RoBust LED Rope Plus Anleitung

RoBust LED Rope Plus 16x8mm
INSTALLATION MANUAL | HANDLEIDING | ANLEITUNG | MANUEL
EN - INSTRUCTIONS
Before installation please read the specifications to make sure
that this product is suitable for the operating environment.
Technical specifications
Input voltage
IP rating
Operating temperature range
Connection
1. Power cord and LED Rope(s) are connectable with male and
female connectors.
2. Insert the pins tightly. Connect with correct polarity +/-
otherwise it will not light up.
3. Twist the spiral nut firmly.
It is possible to connect another LED Rope (with same
specifications and connectors). Maximum length is 100m.
Cutting
To shorten LED Rope: only cut on the cutting mark (every
100cm), otherwise it will cause one whole unit have no light.
Use end cap (146806) which must be filled with a standard PVC
glue to ensure firm connection and watertightness. Add glue on
led rope (1-2cm) and let it dry for a few seconds. Use power
cable (146805) to connect remaining LED rope part.
Warnings - Safety - Caution
• Risk of electric shock. Disconnect power before installation,
servicing and removal.
• Make sure the supply voltage is the same as the rated lamp
voltage.
• All safety instruction must be followed to avoid a risk of injury
or property damage.
• Suitable for indoor and outdoor use.
• Not suitable for use in extreme conditions or locations
involving harmful substances.
• Do not heavy press or overbend during installation and
mounting should be firm, not hanging.
• Do not use iron wire or other metallic wire to fasten.
• Light up for a few minutes to soften the body for easy
installation during cold weather.
• Do not cover the product. Do not attach other items to the
product. Store and install the product out of the reach of
children. Only use the product when it is working perfectly.
• Do not touch the product in the event of a fault or
breakdown. Immediately switch off the product and
disconnect the power supply.
• The following situations are meant by fault or breakdown:
there is visible damage to the product, the product is not
Bailey Electric & Electronics bv - Everdenberg 21 - 4902TT Oosterhout - The Netherlands - +31 (0)162 52 2446 - www.bailey.nl
AC 220-240V
IP65
-20~45°C
working perfectly (e.g. it is flickering), there is a burning
smell, the results of overheating are visible.
• Testing and small repairs must be carried out by a qualified
electrician.
Maintenance
In order not to adversely affect the service life, it is advisable to
clean the fixture on a regular basis. Only use a soft cloth and
water. Avoid exposure to volatile chemical substances such as
alcohol, petrol or pesticides.
Disposal
Electrical products may not be disposed of in the same way as
normal household waste. Take the table lamp to a place where
it can be recycled. Consult the local authorities or the seller for
advice about collection and processing.
Warranty
The warranty period will begin on the day on which the product
was purchased from Bailey and will end after 2 years. If a defect
occurs within the warranty period as a consequence of material
faults and/or manufacturing errors, Bailey will replace the
product. The warranty does not cover consequential damage,
nor will any call-out charges, transport costs or installation costs
be reimbursed. The warranty does not apply if:
• There is no information, or there are no documents, referring
to the date of purchase (invoice or delivery note).
• The model and/or serial number located on the product is
unrecognizable (include photo of product sticker or imprint
with specifications).
• The defect was caused by improper use of the product or
use not as intended, or by use in extreme conditions or in
conditions involving harmful substances.
• Damage to the product was caused by external factors.
• The product is modified.
NL - INSTRUCTIES
Lees voor installatie de specificaties om te controleren of het
product geschikt is voor gebruik in de huidige situatie.
Technische specificaties
Ingangsspanning
Beschermingsgraad
Omgevingstemperatuurbereik
AC 220-240V
IP65
-20~45°C
