ASSEMBLY GUIDE

Preparing for Assembly

TEAM LIFT
With at least two people, lift the
Metal Desk Top and place it upside
down onto a debris-free area to
protect the Metal Desk Top surface.

Connecting the Motorized Leg Columns

Remove the cardboard covers.
Plug the cables on the Left
Motorized Leg Columns and
Right Motorized Leg Columns to
the corresponding colours to
connect them to the Control Box.
Red-to-Red
Yellow-to-Yellow
Metal Desk Top Rear
Note: The additional blue cable connector supplied
is intended solely for the switching of Left Motorized
Leg Column to the right side. Visit our webiste
secretlab.co/resources to refer to the Switching
Integrated Power Supply Column to the Right Side
Assembly Guide for more detailed instructions.
Yellow-to-Yellow
Push Blue into Frame
5
