Eaton BZM2 SIMPLE Montageanweisung Seite 3

SIMPLE: The installation of the auxiliary contacts
M22-K10
M22-K10
M22-K01
M22-K01
M22-K10 M22-K10
M22-K01 M22-K01
=
I
=
th
I I
th
e
U (V) I (A)
e e
AC-15
AC-15
115 4
230 4
400 2
DC-13
500 1
DC-13 24 3
42 1.7
60 1.2
110 0.6
220 0.3
2 x 0.75 - 2.5 mm² 2 x 0.75 - 2.5 mm²
2 x 0.75 - 2.5 mm² 2 x 0.75 - 2.5 mm²
2 x 0.75 - 2.5 mm² 2 x 0.75 - 2.5 mm²
Mounting
Mounting
I
e
U (V) I (A)
e e
115 4
230 4
400 2
500 1
24 3
42 1.7
60 1.2
110 0.6
220 0.3
Z2 Z2
0.8 Nm 0.8 Nm
(7.08 Ib-in) (7.08 Ib-in)
Z2
OFF
Z2
OFF
Z2 Z2
0.8 Nm 0.8 Nm
(7.08 Ib-in) (7.08 Ib-in)
3/6
