7 Installation dimensions
9
All manuals and user guides at all-guides.com
CR refrigerators
B * H * D1
CR 42 380 525 319
*) Bx H = day opening, min dimensions
B * H *
CR 49 380 525
CR 65 450 530
CR 85 475 625
CR 100 485 745
CR130 525 745
*) Bx H = day opening, min dimensions
CR INOX refrigerators
B * H *
CR 42 INOX 400 530
*) Bx H = day opening, min dimensions
B *
CR 49 INOX 400
CR 65 INOX 470
CR 85 INOX 495
CR 130 INOX 545
*) Bx H = day opening, min dimensions
More detailed drawings of the refrigerators can
be seen on: www.indelwebastomarine.com
D2 D3
40 165
DI D2
470 40
500 40
515 40
455 40
505 40
D1 D3
515 165
H * D1
530 510
530 540
625 555
755 545
