8.4. Wiring operating mode M1: Hot water
The protective conductor on the terminal must always
be longer than L and N.
The cable diameter must be at least 1.5 mm².
The phases and the neutral conductor should not be
earthed at the load outputs Out-1 and Out-2. It is not
permissible to interpose an earth leakage circuit
breaker. The load must be connected directly to the
SOL•THOR load outputs.
Only connect resistive loads such as immersion
heaters, electric boilers, convectors, heating mats or
infrared panels. Never connect appliances with
electronic power supplies or thermostats.
It is not possible to operate heaters with electronic
thermostats, fans, motors or a pump!
The maximum power that can be connected to the
output is 3.6 kW.
®
SOL•THOR
Assembly Instructions – Version 250224
20
