5. Technical Specifications
INPUT
Input
MIC MONO
LINE MONO
LINE STEREO
TAPE IN
OUTPUT
Output
STEREO OUT L/R
REC OUT
PHONES
FREQUENCY RESPONSE
Any Input to Any Output
TOTAL HARMONIC DISTORTION
Any Input to Any Output
INPUT CHANNEL EQUALIZATION
High Shelving
Low Shelving
GAIN CONTROL RANGE
Input Channel Trim Control
Channel/Master Faders
CROSSTALK @ 1kHz
Adjacent Channel Inputs
Input to Output
HUM AND NOISE
20Hz~20kHz, Rs = 150Ω, input TRIM @ 0dB, input sensitivity @ -60dB
Equivalent Input Noise
Residual Output Noise
USB
A/D & D/A
Playback
Recording
Interface
VU METERS
4-segment LED x 2
POWER SUPPLY
18VAC/300mA
PROMIX22U_v3
Connector Input Impedance
XLR
¼" TRS
¼" TRS
RCA
Connector Input Impedance
¼" TRS
RCA
¼" TRS
20Hz~20kHz
0.02%, 20Hz~20kHz @ 1kHz, 0dBm
10kHz, +/- 15dB, Q fixed at 2 oct.
100kHz, +/- 15dB, Q fixed at 2 oct.
stop to stop, MIC + 10dB~+60dB, LINE +10dB~+40dB
-∞ to +15dB
-78dB~-68dB
-78dB~-68dB
-129dBm
< 90dBm
Distortion
S/N
Distortion
USB1.1 or USB2.0 w/ full-duplex operation
(playback and recording)
Nominal Level
> 1.3k Ω
> 10k Ω
> 10k Ω
> 10k Ω
Nominal Level
120Ω + 4~6dBm
1k Ω + 4~6dBm
100Ω
6
Max. Level
+ 2dBm + 14dBm
+ 4dBm + 22dBm
+ 4dBm + 22dBm
+ 2dBm + 22dBm
Max. Level
+ 22dBm
+ 22dBm
- 40mW * 2
16-bit ∆ Σ
< 0.05%
80dB
< 0.1%
