6. Input Impedance:
Differential: 8MΩ /1pF
Between terminal and ground: 4MΩ /2pF
7. Output voltage: ≤7V
8. Output impedance: 50Ω
9. Rise time:
7ns
10. Rejection rate on common mode:
60Hz: ＞80dB; 100Hz: ＞60dB; 1MHz: ＞50dB
11. Power Supply: Only External 6V DC power supply.
12. Consumption: 150mA max (0.9 Watt)
3. Operatingenvironmental conditions
Temperature
Relative
Humidity
(1) Dimensions and weight: 69x26x165mm; 500g
(2) Electrical safety to IEC 1010-1
Dual insulation
Installation category Ⅲ
Degree of Pollution 2
Related voltage or max line-earth: 5KV RMS
CE: EN50081-1 and 50082-1
Reference
+20℃...+30℃
≤70%RH
2
Use
Storage
0℃...+50℃
-30℃...+70℃
10%...85%RH 10%...90%RH
