4. Operating procedure
•
Connect the probe to the oscilloscope with the insulated BNC/BNC lead.
•
Adjust the vertical zero adjustment of the oscilloscope if necessary.
•
Select the attenuation ratio* and the vertical deviation of the oscilloscope in
accordance with the conversion table below.
•
NB: The POWER light must come on.
Attenuation ratio
Voltage Input Range
(DC+AC PEAK to PEAK)
[N.B]
The real vertical deviation in V/div is equal to the attenuation factor
multiplied by the range of vertical deviation selected on the
oscilloscope. It will be doubled in the case of use of a 50 Ω load.
5. Maintenance
For maintenance, only use specified spare parts. The manufacturer can not be
held responsible for any accident arising following a repair made other than its
after sales service or approved repairs.
6. Cleaning
This probe does not require any particular cleaning. If necessary, clean the case
with a cloth slightly moistened with the soapy water.
X1000
3000V
3
X100
300V
