Pepperl+Fuchs Tab-Ex 05 DZ2 Kurzanleitung Seite 2

12
11
10
9
8
7
Device layout
1. Front camera / 2. Volume button / 3. Side button / 4. Touchscreen / 5. Back button /
6. Multipurpose jack / 7. Home button / 8. Recent button / 9. Keyboard dock port /
10. WWAN/WiFi SIM card Menory tray / 11. Speaker / 12. Proximity/Light sensor
13. Rear camera / 14. Main antenna (WWAN) / 15. Flash / 16. Ex-Battery Cover / 17. Microphone /
18. Headphone jack / 19. Speaker / 20. NFC antenna / 21. GPS antenna / 22. Microphone
13
1
14
2
3 15
16
4
5
17
6
2
22
21
20
19
18
