Setting the cutting angle (fig. 4)
♦ Loosen the locking screws with the supplied Allen key and pull
the baseplate to the rear.
♦ Adjust the cutting angle to 0° /15° /30° /45° with the aid of the
markings on the baseplate . Push the baseplate to the front so
that the locking pin engages in the toothing .
♦ Re-tighten the locking screws with the Allen key.
Checking the battery pack (Fig 5)
Press the knob on the battery pack to check the battery volume
remains:
4 LED lit = maximum
3 LED lit = 75% volume remains
2 LED lit = 40% volume remains
1 LED lit = empty
Removing/ charging/ inserting the battery pack (fig. 6)
NOTE: The battery pack is delivered partly charged. Charge the
rechargeable battery in the charging station for at least 1 hour
before first use. This will ensure the battery delivers full power.
Li-Ion batteries can be charged at any time without reducing the
life. Interrupting the charging process does not damage the
rechargeable battery.
1. Mounting the battery pack by insert the battery pack into the
slot of the machine. After heard a click denotes the battery
securely locked.
1. To remove the battery pack press the release buttons and
slide the battery pack out of the unit.
2. To charger the battery pack, insert the rechargeable battery
pack into the rapid charger.
3. Insert the mains plug into the mains socket. The status LED
will light up red.
4. The green charging status LED indicates the charging
process has been completed and the battery pack is ready for
use.
MAINTENANCE
Make sure that the machine is not live when carrying out maintenance work on the motor. Regularly clean the machine
housing with a soft cloth, preferably after each use. Keep the ventilation slots free from dust and dirt. If the dirt does not come
off use a soft cloth moistened with soapy water. Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents
may damage the plastic parts.
The machine requires no additional lubrication. If a fault occur, e.g. after wear of a part, please contact your local dealer's
service.
ENVIRONMENT PROTECTION
In order to prevent the machine from damage during transport, it is delivered in a sturdy packaging. Most of the packaging
materials can be recycled. Take these materials to the appropriate recycling locations. Take your unwanted machines to your
local dealer. Here they will be disposed of in an environmentally safe way.
Li-ion batteries can be recycled. Deliver them to a disposal site for chemical waste so that they can be recycled or
disposed of in an environmentally friendly manner.
Discarded electric appliances are recyclable and should not be discarded in the domestic waste! Please actively
support us in conserving resources and protecting the environment by returning this appliance to the collection
centres (if available).
AKKU-PENDELHUBSTICHSÄGE
BESTIMMUNGSGEMÄßER GEBRAUCH
Das Gerät ist für gerade und kurvige Schnitte sowie Gehrungsschnitte bis 45° an kantigen Werkstü cken aus Kunststoff , Holz und
Leichtmetall geeignet. Das Gerät ist ausschließlich für den privaten Gebrauch in trockenen Räumen zugelassen. Beachten Sie
die Hinweise zu Sä geblatttypen. Jede andere Verwendung oder Veränderung des Gerätes gilt als nicht bestimmungsgemäß und
birgt erhebliche Unfallgefahren. Für aus bestimmungswidriger Verwendung entstandene Schäden übernimmt der Hersteller keine
Haftung.
TECHNISCHE DATEN （Abb.1）
Adjusting the pendulum stroke (fig.7)
♦ You can use the pendulum stroke switch to adjust the
pendulum movement of the saw blade . You can achieve
fine, clean-cut edges without pendulum movement (setting
"0").
Deactivate pendulum movement when working on thin
workpieces. You can achieve an increasingly fast work rate
if the pendulum stroke is activated (settings 1–3).
CAUTION! 0 stroke setting is for cutting steel or other
metal, and the the 1-3 stroke setting is for soft workpiece,
such as wood or plastics.
Fitting the guide fence
The guide fence can be fixed on the left- or right-hand side
of the appliance.
♦ Undo both the locking screws on the insertion openings .
♦ Push the guide fence into the insertion openings .
♦ Re-tighten the two locking screws.
Sawdust blowing / vaccum function
♦ Press the sawdust blower switch 7 forwards for dust
blowing function
♦ Press the sawdust blower switch 7 backward for dust
vacuum function.
Switching ON / OFF (see fig. 8)
Switching the appliance on:
♦ Push the safety lock-out (1) to the left or right and keep it
pressed.
♦ Press the ON/OFF switch.
Once the saw is running, you can release the safety lock-
out. The working light illuminates when the ON/OFF switch
is depressed lightly or completely. This allows illumination
of the work area in low lighting.
Switching the appliance off:
Release the ON/OFF switch.
