CORDLESS JIGSAW
ININTENDED USE
This appliance is suitable for straight and curved cutting as well as mitre cuts of up to 45° on angular workpieces made of
plastic, wood and light metal. This appliance is exclusively intended for private use in dry indoor spaces. Observe the guidelines
on saw blade types. Any other usage of or modifi cation to the appliance is deemed to be improper and carries signifi cant risk
of accidents. The manufacturer shall assume no liability for damage attributable to misuse.
TECHNICAL SPECIFICATIONS (see fig 1)
Model
Voltage
Speed
Pendulum settings
Cutting capacity
NOISE/VIBRATION INFORMATION
●
The vibration level given in this information sheet has been measured in accordance with a standardised test given in EN
62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
EXPLANATION OF SYMBOLS
Attention!
Read the manual.
Wear eye protection
Electrical
disposed of with the domestic waste.
PRODUCT ELEMENTS (see fig. 2)
1 Safety lock-out
3 Housing
5 Battery pack
7 Switch for sawdust blower
9 Sliding shoe
12 Guide roller
16 Protector bracket
19 Working light
SAFETY
General Power Tool Safety Warnings
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your
mainsoperated (corded)
(cordless) power tool.
Work area safety
●
Keep work area clean and well lit. Cluttered or dark areasinvite
accidents.
●
Do not operate power tools in explosive atmospheres, such as
CJS-S20Li (JD524220)
20Vd.c.
0-2500 /min
0/1/2/3
Wood: 80mm
Steel: 6mm
appliances must not
power tool or battery-operated
Insulation class
Recommended battery pack
Declared sound pressure level
Declared sound power level
Vibration
Weight:
Pull out mains plug immediately, if the mains cable is
damaged, entangled or severed. Always remove the
mains plug before working on the device.
Wear ear protection.
Wear breathing protection
be Protection class II
2 ON/OFF switch
4 Release button for battery pack
6 Extraction nozzle
8 Base plate
10 Pendulum stroke switch
13
Saw blade
17 Quick-release chuck
in the presence of flammable liquids, gases ordust. Power
tools create sparks which may ignite the dust or fumes.
●
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
Electrical safety
●
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
●
Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric shock if your body is earthed
or grounded.
III
CLB-20V-4.0
LpA: 76.12dB(A), KpA=5dB(A)
LwA: 87.12dB(A), KwA=5dB(A)
2 2
ah=4.68m/s , K=1.5m/s
2.2kg
4
