Replacing the battery

WARNING: Power off before attempting any adjustment, replacement or repair.
If you need to replace the battery, follow these steps:
1. Turn your Mower upside down.
2. Remove the 4 screws on the battery cover. Remove the battery cover.
3. Lift out the old battery carefully. Press the latch and release the connectors.
NOTE: Do not pull by the cables. Hold the connectors and release the latch.
4. Connect a new original battery by attaching the connectors until they click into
position.
5. Fit the battery as shown,Place the cover back in its position and tighten the screws.
Battery pack
Installation Boundary wire
When laying the boundary wire, use the distance gauge to keep a 25cm* space between
the wire and perimeter, Each wire peg should be placed around 80cm apart, use the
provided distance gauge to ensure proper installation. The ground is uneven area, the peg
density can be increased appropriately.
Battery bracket 2
13
Battery cover
