Kaco RCN-KIT Kurzanleitung Seite 5

5. Connect-RCN (Communica�on device)
1
2
1
3
OK
OK
click
3
2
1
3
4
Pin 1 Pin 8
8 7 6 5 4 3 2 1
Patch cable: CAT 6E
Cable length: ＜ 30m
2
4
EN
Pin 1=+12V
Pin 2=GND
Pin 3=DI1
Pin 4=DI2
Pin 5=DI3
Pin 6=GND
Pin 7=DI4
Pin 8=NA Input Signal
1
2
OK
