Kaco RCN-KIT Kurzanleitung Seite 2

1.Delivery Content
RCN Connection Box
2. Overview of the connec�on area
Assignment of the terminal block:
1 2 3 4 5 6 7 8 9 10
Terminal (10 pin) x1
Connect-RCN x1
PIN
1
2
3
4
5
6
7
8
9
10
EN
Quickguide x1
Assignment
+12V
GND
GND
DI1
DI2
DI3
DI4
GND
NA Input Signal
GND
