Kaco RCN-KIT Kurzanleitung Seite 3

Assignment of the connec�on area:
NO Name
RJ45 Socket
A
B Communica�on Port
- knockout seal
C
Power supply Port
3. Moun�ng
1
3
A B C
PH1
2/3 X
Descrip�on
Connect - RCN
Input for Ripple Controller Reciever &
NA-Protec�on
Power supply socket, connect to 12V
power adapter
2
IP22
indoor
EN
60.00 mm
φ4.2 mm(x3)
