DeWalt DWP849X Originalanweisungen Seite 25

Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal in the plug.
• Connect the blue lead to the neutral terminal.

WARNING: No connection is to be made to the
earth terminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13 A.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data). The minimum conductor size is 1.5 mm
maximum length is 30 m.
When using a cable reel, always unwind the cable completely.
Package Contents
The package contains:
1 Polisher
1 Auxiliary handle
1 Bale handle
2 Wool ingestion shields
1 180 mm hook and loop backing pad
1 180 mm hook and loop wool polishing pad
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred during transport.
• Take the time to thoroughly read and understand this manual
prior to operation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Always operate with two hands.
Date Code Position (Fig. A)
The production date code
11
by a 2-digit week and is extended by a 2-digit factory code.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury could result.
Speed control wheel
1
Variable speed trigger switch
2
Brush inspection cap
3
Spindle lock button
4
2
consists of a 4-digit year followed
Auxiliary handle
5
Trigger locking button
6
Bale handle
7
Spindle
8
Soft rubber gear case cover
9
Wool ingestion shields
10
Date code
11
Intended Use
Your DWP849X heavy-duty polisher has been designed for
polishing painted or unfinished metal, fiberglass, and composite
surfaces in professional applications. Common examples of
use include but are not limited to: auto/marine/RV/motorcycle
detailing and finish correction, boat construction and repair, and
metal or concrete finishing.
; the
DO nOt use under wet conditions or in the presence of
flammable liquids or gases.
These heavy-duty polishers are professional power tools.
DO nOt let children come into contact with the tool.
Supervision is required when inexperienced operators use
this tool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from
power source before making any adjustments or
removing/installing attachments or accessories.
Before reconnecting the tool, depress and release the
trigger switch to ensure that the tool is off.
Auxiliary Handle (Fig. A)

WARNING: Before using the tool, check that the handle is
tightened securely.
An auxiliary handle
installed on either side of the gear case. This handle should be
used at all times to maintain complete control of the tool.
A bale handle
7
used in place of the auxiliary handle.
Wool Ingestion Shields (Fig. A, B)
The wool ingestion shields
amount of wool, dust, and debris that gets ingested by the
motor during normal use.
Clean the shields as soon as you start to see buildup on the
outside. To clean the wool ingestion shields:
1. Remove the mounting screw
2. Slide the shield back toward the trigger end of the tool and
lift it off.
3. Clean with soap and water and a soft bristle brush.
4. Replace the shield on the tool and tighten the
mounting screw.
5 is supplied with your tool and can be
is also supplied with the DWP849X and can be
10 are designed to reduce the
.
12
