D32 PRO Structure Mode Selection Instructions
Overview
Micro-ATX
(Regular)
Micro-ATX
(Back-Connect)
CPU Cooler Height Limit
Memory Height Support
Space For GPU Power
Cables
Note: You need to confirm and manually adjust the chassis structure mode in advance according to the hardware specifications before
assembling the hardware.
概述
M-ATX标准型主板
M-ATX背插型主板
CPU散热器限高
内存高度支持
GPU供电线空间
注意：需根据硬件规格，提前确认并手动调节机箱结构模式，再进行硬件装配
6
A Model（Factory Default）
Compatible with common motherboards, with a larger
motherboard compartment space, suitable for most
users. This mode is the factory default
Compatible
Incompatible
≤170mm (Intel CPU)
≤169mm (AMD CPU)
At least 51mm, depending on the relative position of
the memory and the water cooling radiator
Less strict
D32 PRO 结构模式选择说明
A模式（出厂默认）
兼容普通主板，拥有较大的主板仓空间，适合大多数用
户使用，出厂默认为此模式
可兼容
不兼容
≤170mm (Intel CPU)
≤169mm (AMD CPU)
至少51mm，具体取决于内存与水冷散热器相对位置关系
较宽松
B Model
Compatible with Micro-ATX (Back-Connect), with a large
back plug-in space, suitable for back-plug motherboard
users
Compatible
Compatible
≤164mm (Intel CPU)
≤163mm (AMD CPU)
At least 45mm, depending on the relative position of
the memory and the water cooling radiator
Depends on the width of the graphics card
B模式
兼容背插主板，拥有较大的背部插线空间，适合背插型主
板用户使用
可兼容
可兼容
≤164mm (Intel CPU)
≤163mm (AMD CPU)
至少45mm，具体取决于内存与水冷散热器相对位置关系
视显卡宽度尺寸而定
