Chassis Structure Mode Description / 机箱结构模式说明
Description du mode de structure du châssis / Beschreibung des Chassis-Strukturmodus /
Descripción del modo de estructura del chasis / 섀시 구조 모드 설명
D32 PRO has a structure that can adjust the internal bin allocation ratio. You need to choose
the appropriate mode based on the hardware configuration
D32 PRO拥有可调整内仓分配比例的结构，需依据硬件配置，选择合适的模式
A-MODE STRUCTURE SPACE DATA
A模式结构空间数据
Tip: This mode is the factory default
提示：此模式为出厂默认
B-MODE STRUCTURE SPACE DATA
B模式结构空间数据
Tips:
1. Mode B needs to be switched manually before hardware assembly. For details on how to switch, please go to page 10~17
2. If you install a Micro-ATX (Back-Connect) in B mode, you need to carefully arrange the back cables and then install the
back side panel to complete the installation
提示：
1. B模式需硬件装配前手动切换，切换方式请跳转第10~17页查看详情
2. B模式下如果安装背插型主板，需仔细整理背部线材后，再安装背部侧板完成装机
