WARNING
1) Please make sure to turn o the power before starting the installation.
2) Observe the connection diagram provided before connecting to the power supply
3) Installation should be done by a qualified electrician.
4) Disconnect the power supply when wiring or soldering the LED.
5) Please ensure to check the DC output of the power supply matches with the DC
Input of the striplight.

CONNECTION DIAGRAM

Neutral - black or blue
Earth - yellow or yellowgreen
Live - brown or red
INSTALLATION
1. Please make sure to turn o the power before starting the installation.
2. Plug the AC source of the adaptor into the AC input source.
3. Connect the DC output of the power supply unit to the strip light as shown below.
Note: If the strip light is not included with a DC connector - Please wire the DC input of the striplight with a DC
female connector(not included in the scope of delivery) and connect it to the DC connector of the power supply.
4. Plug the power adapter into the socket to illuminate the whole system.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
SUPPORT@VTACEXPORTS.COM V-TAC HOUSE, KELPATRICK ROAD, SLOUGH, BERKSHIRE, SL1 6BW, UK.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
AC Outlet
Strip light
