TENS STIMULATION
Programs 1–16 have preset parameters which have proven
beneficial for their respective fields of application. These
settings may also be used for other indications under certain
circumstances, as each patient responds in a highly individual
way to stimulation.
EN
Always start with the lowest intensity and increase it until a
tingling sensation is felt. All programs are different and therefore
feel different. You can try all the programs at the start and choose
the one that feels comfortable. Increase the intensity slowly and
never to the point where it hurts. The stimulation should not feel
uncomfortable. Start with short sessions of 5 or 10 minutes until
your body gets accustomed to the stimulation.
Note: For all TENS programs, the standard application duration is
30 to 45 minutes.
TENS-programs P 01–P 16
P 01
P 02
P 03
P 04
P 05
50
Classic TENS mode
Pulse frequency: 80 Hz | Pulse width: 180 μs
Applicable to most acute and chronic types of pain.
Gate control effect
Low frequency burst TENS
Pulse frequency: 2-100 Hz | Pulse width: 180 μs
Endorphin release. For application on arms, legs,
knees and lower back
Modulated TENS
Pulse frequency: 80 Hz | Pulse width: 70-180 μs
To counteract habituation effect with prolonged use.
Applicable to most acute and chronic types of pain
Alternating frequency 15/2 Hz
Pulse frequency: 2-15 Hz | Pulse width: 180 μs
Application on joints, neck and lower back
Alternating frequency 80/2 Hz
Pulse frequency: 2-80 Hz | Pulse width: 180 μs
For long-term treatments. Effective for most pain
indications
