Thermal Imager / English
Charging system In camera (AC adapter)
Power management Automatic shutdown
Environmental data
Operating temperature range -15°C to +50°C (5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) 10%~90%
Drop test 2m
Bump 25g(IEC60068-2-29)
Vibration 2g(IEC60068-2-6)
Physical data
Camera weight, incl. battery <500g
Camera size (L × W × H) 224x77x96mm
5. Before You Start
5-1. How to Charge the Battery
Before you use the Thermal Imager for the first time, charge the battery for three and three-
half hours. The battery status shows on the six-segment charge indicator.
To charge the battery, use follow before:
1. Connect the ac power adapter into an ac wall outlet and connect the dc output to the
Thermal Imager's ac power socket, the charge light is on. The battery indicator becomes
"
the ac power adapter.
2. Charge until the charge indicator becomes
3. Disconnect ac power adapter when the battery is full charged.
Note: Make sure that the Thermal Imager is near room temperature before you connect it
to the charger. Do not charge in hot or cold areas. When you charge in extreme temperature,
battery capacity may be decreased.
8
", while the battery charges with
, the charge icon not changed .
5-2. Power On
To turn the Thermal Imager on, push the Power
Button.
Note: After power on the device, The thermal Imager needs sufficient warm-up time for the
most accurate temperature measurements and best image quality. So the visible image will
first appear, and the thermal sensor will calibrate internal for sevearal seconds. After that the
thermal image will be displayed on the screen.
5-3. Power Off
When Thermal Imagers power on, Push and hold the Power
popup the power off menu, press "OK" to power off the device. Push and hold the Power
Button for twelve seconds, the device will be forced power off directly.
Thermal Imager / English
Button for two seconds, then
9
