Beetronics User Manual | Bedienungsanleitung | Manuel d'utilisation
Installing the monitor
Installing the monitor
Package contents
To get started, unpack the box and verify that the following items are included.
A.
Touchscreen
WARNING! Do not use any unapproved accessories to ensure the safety and product life span. Any damages or injuries caused by
using unapproved accessories are not covered by the warranty.
Setup
Please read the supplied instruction manual and follow all safety precautions before setting up the monitor. Turn off the source and
monitor before connecting to protect equipment. Check the surrounding environment for temperature and humidity within specified
limits (as outlined in the manual) when setting up the monitor. After positioning the monitor, follow these steps to connect:
1. DC
2. HDMI, DP, VGA, USBC
B.
Mounting Kit
C.
Sealing
ring
Screws | 8x
Clamps | 8x
Mounting
strips | 8x
3. USB TOUCH
D.
Remote
E.
F.
USB-C to USB-C
(Video, audio, touch)
1.
Plug the power adapter into the 5.5mm DC port located at the rear
of the display. Please note that the power adapter is required,
even when using the USB-C connection.
2.
Select your preferred video cable (HDMI, DisplayPort, VGA, or
USB-C) and connect it to the corresponding ports on the source
and the monitor.
3.
If you are using USB-C for video in step 2, you can proceed to step 4.
Otherwise, connect the preferred USB-touch cable (USB-C to USB-A
or USB-C to USB-C) to the USB-C touch port.
4.
Switch on the device that will provide the video signal.
5.
Power on the touchscreen. It will automatically recognize the
connected video input, switch to the appropriate input channel, and
display the signal transmitted by the source.
Power adapter
G.
USB-C to USB-A
(Touch only)
H.
Quickstart
10
