Install a Wedge (Optional)
If you need to adjust the angle of the doorbell, you can use the wedge
provided. (The Reolink Video Doorbell PoE is taken as an example)
1
Step 1
Put the mounting hole template on the wall and drill holes as shown.
Step 2
Install the wedge using the screws provided through the two holes. Ensure
that the notched side of the wedge is facing outside.
Step 3
Notched Side Facing Doorbell
2
Screw the mounting plate to the wedge.
Step 4
Run the Ethernet cable through the wedge and mounting plate, and
1
attach the doorbell to the plate.
2
