6.9
abmessungen
23-3 Serie
ø 57.15 (2.25)
154 (6.00)
137 (5.5)
AUSGANG/
OUTLET
19
(0.75)
Maße in mm (inch)/
Dimensions in mm (inch)
TESCOM EUROPE GMBH & CO. KG
An der Trave 23 - 25
Tel: +49 (0) 3 88 23 / 31-0
eu.tescom@emerson.com
04/08 GA D43455 AEZ. 07
1/8-27 NPT
(positionierbar)/
1/8-27
(positionable)
EINGANG/
INLET
ø 60 (2.37)
ø 68,6 (2.7)
D-23923 Selmsdorf
•
Fax: +49 (0) 3 88 23 / 31-199
•
www.tescom-europe.com
•
6.9
34.9
(1.375)
Befestigungsbohrbild/
Panel cut-out
Germany
•
24
Dimensions
23-3 Series
2 x M5
7 (0.28) tief/full thread
2x ø5.2 (0,203)
