1 ELECTRICAL SAFETY
INSTRUCTIONS
1
Before connecting the dispenser to the mains,
check that the voltage shown on the rating plate
matches your electricity supply. Connect the
dispenser to a single-phase supply through an
earthed socket as required by current regulations. If
the dispenser is to be disconnected from the power
supply using a single pole switch, the gap between
the contacts on this switch must be sufficiently wide
to guarantee full disconnection under category III
overload conditions.?
2
Do not use extension cables to connect the
appliance.
3
To avoid any risks, if the power cable is
damaged, it must be replaced by the manufacturer,
by an authorised technician or by a similarly
qualified person.
4
The dispenser is not suitable for outdoor use.
5
The dispenser must be installed in the upright
position and always handled with care. If, even
during transport, it has been positioned horizontally,
wait 4 hours after installation before starting.
6
Before cleaning,
dispenser by removing the plug from the socket.
7
Always disconnect
r e m o v i ng a ny o f t h e p a n e l s f o r c l e a ni n g o r
maintenance work.
8
This appliance must not be operated by
children.
9
Do not let children play with the appliance.
10
This appliance must not be used by persons
w i t h r e d u c e d p h y s i c a l , s e n s o r y o r m e n t a l
capabilities or with a lack of experience and
knowledge unless they have supervision or have
been trained regarding the safe use of the appliance
and understand the risks involved.
11
Only persons who know and have practical
experience of the appliance are permitted access to
the inner components of the dispenser, especially
when dealing with issues regarding safety and
hygiene.
12
If the symbol (see picture 1 - page 4) is present;
DANGER: risk of fire.
2 HYGIENIC SAFETY INSTRUCTIONS
1
This appliance is intended exclusively for
domestic and similar use.
2
For the appliance to operate correctly, room
temperature must be between +5° and +32°C.
3
Use the appliance to cool the indicated liquids
only.
4
Do not introduce dangerous or toxic liquids to
the appliance.
always disconnect
the dispenser before
3 TECHNICAL CHARACTERISTICS
Bowl capacity, approx
Evaporator capacity, approx
Dimensions:
width
depth
height
Net weight, approx.
Gross weight, approx.
Hermetic compressor
Air-cooled condenser
the
Overload protector
Noise level lower than 70 dB (A)
IMPORTANT
Electrical
featured on the data plate of each dispenser;
this data plate is situated in the lower part of
the front panel, behind the drip tray. The serial
numbers of appliances (preceded by the
symbol #) are indicated on the frame, at the
rear of the appliance, behind the condenser
cover panel. The data specified on the data
plate are always those you should refer to.
The manufacturer reserves the right to amend this
manual without notice.
4 INTRODUCTION
Read this instruction manual carefully to find out all
the characteristics of the dispenser.
As with all mechanical products, this dispenser also
requires cleaning and care. In addition, its correct
operation may be compromised by possible errors
made by the operator during the disassembly and
cleaning operations. For this reason, it is important
that the disassembly, cleaning, sanitising and
reassembly procedures - being everyday tasks - are
familiar, without any room for error on the part of the
dispenser user.
characteristics: read
l 4
l 2
cm 26
cm 57
cm 72
kg 50
kg 55
the data
